Quadrant Crunching Cyber example

Recently I focused more on the phenomenon of BIAS and supporting decision makers to minimize BIAS in their decisions. I provide a Quadrant Crunching Cyber example here. To demonstrate that these are things that the BCM manager and the Risk Manager can deliver (together). The example serves only as an academic illustration, not as a thoroughly developed analysis for a logistics organization.

In this contribution I give my own opinion, not that of any organization.

Author: Manu Steens

I recently gave a first introduction to Structured Analytic Techniques for Intelligence Analysis, which can be used in risk analysis exercises and crisis exercises in decision making.

One question I received was, “Can this also be used in BCM?” The answer was “Yes”. And promise is debt, of course. The idea was that Quadrant Crunching is useful for identifying weaknesses of an organization in the face of a threat.

As an example here, I’ll throw in a logistics institution with cyber risks as a threat.

What does the analysis technique “Quadrant Crunching” do

Quadrant Crunching helps the analyst avoid surprises by systematically examining the extensiveness of possible combinations of selected key variables. Those Key Variables are “parameters” that make up a hypothesis of a crisis. Thus, the more extensive the number of meaningful combinations, to the more extensive the number of possible types of crises.

In this way, Quadrant Crunching greatly broadens the view of possible vulnerabilities, and avoids such things as tunnel vision, group thinking, recency bias, etc. …

When do you use Quadrant Crunching

You use it in very complex and highly ambiguous situations with little data available and with a lot of potential for surprises.

You can use Classic Quadrant Crunching here to generate many possibilities and systematically challenge the assumptions made.

How does the analysis procedure work: The Method

• The starting point is a well-defined “lead hypothesis”. This is a sentence that describes a crisis with the essential components listed in it. These are the answers to the questions journalists tend to ask. These are the ‘Who’, ‘What’, ‘Where’, ‘When’, ‘Why’ and the ‘How’ from a ‘STAR’ analysis.
• This lead hypothesis is divided into its components. These components are the “key assumptions” of the lead hypothesis. One further unravels the key assumptions into key dimensions.
• After these key assumptions, the analyst generates two, four, … more examples of ‘contrary assumptions’. He does this by varying the assumptions and dimensions of the lead hypothesis.
• Combinations of two contrary dimensions are placed in sets of 2 x 2 matrices. With 4 quadrants each. The number of combinations increases rapidly according to the number of dimensions. This can make placing in quadrants a lengthy task.
•  Create one or more stories for each quadrant.
• Identify and remove the wrong combinations. These are combinations that cannot or are difficult to combine. For example, a ransomware attack that is simultaneously a wiping attack.
• Select a few stories that deserve the most attention according to a set of predetermined criteria. These will be the most important scenarios. These criteria are criteria for the benefit of the opponent’s goals. If useful, combine a number of stories from different matrices.
• Make a list of indicators for each story.
• Determine and implement measures for the most important stories / scenarios. Determine further measures for when a scenario (story) starts up.
• Monitor the system according to the indicators.
• Determine which scenario starts as soon as an indicator indicates it.
• Notify the decision makers. Decide on further steps.

Illustration using an example

The example here for illustration is that of a Cyber-attack on a logistics organization. Whether by hybrid war or NSA (Non State Actors) or not.

The method works by starting with an initial scenario that is sufficiently well defined. A tool here to establish this first scenario is the STAR method, which actually focuses on the questions Journalists often ask: Who, What, Where, When, Why, How. The “lead hypothesis” here, which we will assume in this exercise, is:

“A ransomware attack, on the cloud services of the ICT provider (of a logistics organization), carried out by an NSA, against customers in the logistics organization’s supply chain as victims.“

I take out the “of a logistics organization” component because in this case it is always against its own organization. If it were a study regarding all possible organizations, it is possible to keep this component.

When generating a lead hypothesis, it is permissible, even good, to use a recent incident from the news as inspiration.

This base scenario is then unraveled into its components, called key assumptions, as follows:

• a ransomware attack,
• on the cloud services of the IT supplier
• carried out by an NSA,
• against customers in the supply chain of the logistics organization as victims

Against these key assumptions in the scenario we now systematically place so-called contradictory assumptions and their dimensions. Doing this increases the number of scenarios very quickly, because one can then randomly start combining them. Some possibilities (non-exhaustive list) are:

First scenario	Conflicting assumptions	Dimensions
A ransomware attack	Other type of attack	DDOS attack
		Wiping attack
		Phishing attack
		Social engineering
		Data theft
		Data corruption
		Easter eggs
		Logical bomb
		Malware attack
		Rootkit attack
		Hardware theft
		Spyware
		Man in the middle attack
		Hacking
		Identity theft
		Combination of the above
On the cloud services of the ICT supplier	At the organization itself	On the servers at the organization itself (Purchase, Sales, Maintenance, HR, Warehouse,…) (ERP package, distribution,…)
		On the servers at the organization itself (Firewall, monitoring systems, helpdesk, website,…)
		On the PLC/ SCADA systems
		On an employee’s laptop (Office systems, communication systems…)
		On an employee’s smartphone (address book, Whatsapp, Messenger, Teams, Photos…)
		On an employee’s tablet (Office systems,…)
	At the internet provider	Attack on their confidentiality
		Attack on their availability
		Attack on their integrity
		Attack on non-repudiation
	At the customer	On the servers
		On a laptop
		At their ICT supplier
		At their internet provider
	At a commodity supplier	On the servers
		At a laptop
		At their ICT supplier
		At their internet provider
		At their software
	At banks	On the method of payment
		Attack on their confidentiality
		Attack on their availability
		Attack on their integrity
		Attack on non-repudiation
Conducted by an NSA	By an acquaintance	By an employee
		By a consultant
		By a visitor
		By a relative of an employee
		By an action group
	By a State Actor	By military IT services
		By spies
		By intelligence services
	By unknown persons	By Anonymous
		By an unknown cybercriminal collective
Against customers in the logistics organization’s supply chain as victims	Damage to customers of customers	The man in the street (B2C customers).
		Firms that ordered from the customer B2B.
	Damage to suppliers of the organization	Payment systems of the organization
		Communication systems
	Against people of the organization	Members of the C-suite or the board
	For gaining profit at the expense of the organization	Extortion
		Theft of finances
		Intellectual theft
		Theft of goods

Further progression

Plot each of the possible two-by-two combinations of dimensions in matrices. For each cell in each matrix, give 1 to 3 possible examples of scenarios. In some quadrants, there may be no realistic scenarios. You then ignore those. Some quadrants will prompt thought, and cause new dynamics to be considered.

Criteria to help evaluate here what is very realistic are:

• Maximum damage, maximum impact, provides maximum gain for the perpetrator(s).
• Difficult to detect (the preparation and implementation) (Or rapid implementation).
• Provides a difficult challenge to address.

Sometimes cells can be taken together. Combining additional ones makes many scenarios concrete.

Nightmare story: Wiping of the CAAS (Cloud as a service) by an intelligence services organization.

Duties of the CRO and Business Continuity Manager

• Consider what decision makers can do to prevent bad stories, mitigate the impact, and deal with the consequences.
• Generate a list of key indicators that help evaluate whether any of these attack plans are in the start-up phase.
  • Monitoring hits on firewalls.
  • Reports of regular intrusion detections
  • Monitoring of honeypots
  • Regularly hashing the root software, and comparing it to the original hash
  • Monitor instabilities in systems
• Together with the ICT security specialist, implement security methods using ISO-27K standards and NIST standards and the like.
• Determine follow-up decisions for when a scenario unfolds as advice to decision makers. Determine the subsidiarity of decisions in that. Do this using action fiches.

An example of content for a fiche for a DDOS attack

Definition – Introduction: Distributed Denial of Service (DDOS attack)

A DDoS attack is a cyber-attack in which a large amount of data traffic is sent to the target website or Web server in a coordinated manner. The goal is to overload it and make it unreachable.

To avoid the worst, you need to (know/) do 2 things:

(1) (how) to prepare, and

(2) (how) to deal with the situation.

How to prepare

What to do	Motivation
Create awareness – Risk communication.	People will then not start calling the IT help desk or IT operations en masse. So they will not be disturbed or less disturbed in dealing with the situation.
Monitor data traffic continuously	Measuring is knowing. You can automate detection and then react to unusual traffic.
Create a DDoS action plan and empower IT staff.	The IT department will know what to do and they can do it immediately. (Including offline retrieval of the sites.)
Train like you fight, practice !	Gain experience with preventive shutdown of websites.
Increase bandwidth capacity.	You can handle more traffic before problems arise.
Protection services from specialized providers.	They can filter attack traffic before it arrives. That way, they ensure website availability.
Implement load balancing.	Less risk of overloading a single point
Rate-limiting.	Limit the number of connections from a single IP address.
Choose your ISP (Internet Service Provider) wisely.	Some have good tools to limit DDOS attacks

How to deal with it

What to do	Motivation
Monitoring gives alarm	There is an abnormal level of data traffic on the website
Fight like you train: start implementing the DDOS action plan	The alternative is that the website or service becomes slow or crashes completely
Crisis communication to employees with the MNS (Mass Notification System)	We know – We do – We care – We will be back to you. This message must exist in advance.
Communicate with the CMT (Crisis Management Team).	They can issue additional orders, if they deem it necessary
Check the “supply-chain ecosystem.	There may be attacks on other organizations in the supply-chain, or on other departments of one’s own organization.
Communicate with the CCB (Center for Cybersecurity Belgium).	A logistics organization is an important social service. Therefore, they may need to apply NIS2 regulations. I chose the CCB here because Belgium is a hub for logistics mobility in Europe.

Contacts

Who	Contact details	Who	Contact details
CMT & CISO	Permanent telephone number	COO	Telephone no
Employees	See Mass Notification System	ISP	Permanence phone no ISP
CCB Notification	info[at]ccb.belgium.be	Suppliers	Suppliers list URL

Possible objectives of such an exercise

One of the main goals is to identify realistic scenarios and thereby generate a set of indicators needed to recognize the emergence of problems, or the recognition of an ongoing problem, or the emergence of new problems on the sidelines. This with the goal of creating EWSs (Early Warning Systems) that can alert the stakeholders of the concerned organization. To this end, one can already rely on the third column after drawing up the conflicting assumptions and associated dimensions.

The preparation of action fiches on possible types of attacks for the benefit of the CMT is also useful as an explanation of the course of the proposed approach to the crisis.

Another purpose, rather on the periphery, is to identify an exercise scenario, where the Business Continuity manager or the CRO would like to bring additional attention to a particular problem.

Most importantly, however, it counters tunnel vision by being an eye opener regarding cyber vulnerabilities for the CISO, CRO, help desk, IT operations and the Business Continuity Manager, and upper management.
